Products Description
Outline overall & Installing dimensions(mm)
Working Principle
When the isolation switch is switched on, it is operated with an insulation hook. The insulation hook hooks into the isolation switch lock hook, pulls the lock hook to the opening direction, unlocks the self-locking device and drives the conductive plate connected with it to rotate to realize the opening action. When closing, the insulating hook rod holds the isolation switch lock hook and drives the rotating shaft to rotate, so that the conductive plate connected with it rotates to the closing position. At this time, the self-locking device locks the isolation switch in the closing position.
This type of isolation switch can be installed on the pillar, wall, ceiling, cross frame or metal frame, can also be vertically installed, inclined installation, but the installation position should be so that when the contact knife is opened, it tends to the lower.
Products Advantage
This isolation switch offers outstanding performance and significant benefits. Its insulator is made of advanced ceramic material, which is not only strong in texture, but also able to withstand long-term mechanical stress and electrical load, ensuring the durability of the equipment, greatly extending the service life of the isolation switch, reducing the frequency of replacement and maintenance costs. At the same time, ceramic materials can effectively resist the erosion of dust, dirt and various corrosive substances, and can also operate stably in complex and harsh environments.
In the contact design, the use of integrated type structure, this unique design makes the contact electrical conductivity is very excellent. The integrated forming avoids the problems such as poor contact and increased resistance that may exist in the traditional splicing contacts, and the current can be transmitted smoothly in the contacts, reducing the power loss, improving the power transmission efficiency, ensuring the efficient and stable operation of the power system, and providing reliable power support for various scenarios.
